Product standards

GB 15811-2016 Disposable Sterile Injection Needle

"YBB00112004-2015 Pre-potting Syringe Assembly (with needle)"

"YBB000992004-2015 Stainless Steel injection needle for pre-potting syringes"

GB/T 18457-2015 Stainless Steel syringes for manufacturing medical Devices

Equipment characteristics

7 inch color touch screen operation, easy and reliable operation;

Three-level management authority setting to meet GMP requirements;

One machine can meet the needs of customers;

Cost-effective design, reduce procurement costs;

High precision sensor, more accurate test results;

Large capacity results storage to meet customer storage needs;

Full keyboard number setting, easily distinguish sample categories;

Test principle

Rigidity: A specified force is applied to the center of the specified span of the needle being supported at both ends, and the deflection value of the needle is measured.

Toughness: Fix one end of the needle, apply a force from the fixed point to the specified span of the needle, first bend a specified Angle in one direction, and then bend a specified Angle in the opposite direction, and so repeatedly bend the specified number of times.

Product parameters
