Introduction

PMT-B breaking force tester is a medical packaging series professional instrument for ampoule breaking force testing, to meet the GB2637, YBB00332002 standards for ampoule breaking force device requirements. The instrument can also be extended to perform other tubular or fracture force tests that require fracture force.

The breaking force tester adopts imported brand high-precision sensor, the test results are accurate and stable, and the stepless speed regulation can meet the requirements of different experiments on the test speed. Instrument equipped with 1ml, 2ml, 5ml, 10ml, 20ml five kinds of fixture, easy to replace. Equipped with protective cover and automatic discharge structure, it is convenient to collect damaged samples and check the damaged condition of the samples. Widely used in drug testing institutions, pharmaceutical packaging material manufacturers, pharmaceutical enterprises, medical equipment manufacturers, cosmetic manufacturers and other units.

Features

● Imported microcomputer control technology, open structure, friendly man-machine interface operation, easy to use

● A variety of operating modes can be arbitrarily selected, increasing the fixed force value, positioning and shifting mode, making the operation more simple and convenient

● Precision screw drive, high-quality stainless steel guide rail and reasonable layout, to ensure the smooth operation of the instrument

● Imported high-precision force sensor, measuring accuracy of 0.5

● Precision differential motor drive, more stable transmission, lower noise, more accurate positioning, better repeatability of test results

● LCD Chinese display, automatic measurement, with the test data statistical processing function

● High speed micro printer output, printing fast, low noise, no need to change the ribbon, easy to change the paper roll

● Built-in special calibration program, easy to measure, calibration department (third party) to calibrate the instrument

● High definition color large screen display curves, text, visual clearer

● Can be equipped with computer software, two-way operation

Technical parameters

Standards

GB2637, YBB00332002 –2015
